    ASTM F67 Medical Titanium Rod Gr1ELI TA1ELI Titanium rod bar

    Ask Lasest Price
    Brand Name : PRM
    Model Number : Gr1ELI TA1ELI
    Certification : ISO9001
    Price : $15~30/kg
    Payment Terms : T/T
    Supply Ability : 50ton/month
    Delivery Time : 5~7days
    • Product Details
    • Company Profile

    ASTM F67 Medical Titanium Rod Gr1ELI TA1ELI Titanium rod bar

    Medical Titanium Rod:


    Specifications:Rolling ¢8.0---40mm× L; Forging ¢40---150mm×L
    Metallurgical structure:Pure titanium grain size is not less than grade 5, TC4 titanium alloy meets A1-A9.
    Surface:Black leather surface, polished surface, polished surface (H11, H9, H8)
    Performance of medical titanium rodsreference implementation standards: GB/T13810-2007, ASTM F67/F136

    Room temperature properties of medical titanium rods GB/T13810-2007:


    Grade
    Status
    Diameter or side length
    Tensile strengthσb
    Yield Strengthσ0.2
    Elongation after fracture
    Rate of reduction in area
    mm
    MPa
    MPa
    A%
    Z%
    TA1ELI
    M
    >7~90
    ≥200
    ≥140
    ≥30
    ≥30
    TA1
    M
    ≥240
    ≥170
    ≥24
    ≥30
    TA2
    M
    ≥400
    ≥275
    ≥20
    ≥30
    TA3
    M
    ≥500
    ≥380
    ≥18
    ≥30
    TA4
    M
    ≥580
    ≥485
    ≥15
    ≥25
    TC4
    M
    >7~50
    ≥930
    ≥860
    ≥10
    ≥25
    M
    >50~90
    ≥895
    ≥830
    ≥10
    ≥25
    TC4ELI
    M
    >7~45
    ≥860
    ≥795
    ≥10
    ≥25
    M
    >45~65
    ≥825
    ≥760
    ≥8
    ≥20
    M
    >65~90
    ≥825
    ≥760
    ≥8
    ≥15
    TC20
    M
    >7~100
    ≥900
    ≥800
    ≥10
    ≥25
    Note: For titanium bars with a diameter greater than 75 mm, take the bar-shaped specimen.

    The mechanical properties of medical titanium rods comply with GB/T13810-2007 and ASTM F67/F136.


    Using titanium rods to make artificial bones, cells can regenerate on them and bones can grow. Titanium has good affinity with human bones, epithelium, and artificial tissue. In order to improve the surface quality of implants connected to human bones, applying a bioceramic layer to the roughened surface is also a more effective method.
