    99.95% Strip Molybdenum Heating Element For Hot Zones Molybdenum Heater Molybdenum Heating Elements Moly Rod

    Ask Lasest Price
    Brand Name : PRM
    Model Number : Heat Element
    Certification : ISO9001
    Price : $50~150/kg
    Payment Terms : T/T
    Supply Ability : 2000kgs/month
    Delivery Time : 7~10 work days
    • Product Details
    • Company Profile

    99.95% Strip Molybdenum Heating Element For Hot Zones Molybdenum Heater Molybdenum Heating Elements Moly Rod

    Molybdenum Heat Element For Hot Zones


    1. Description Of Molybdenum Heat Element For Hot Zones:


    The commonly used models of molybdenum heating element are molybdenum wire heating element and molybdenum rod heating element. There are two types of molybdenum wire heating elements: one-section and two-section. They are constructed from many strands of molybdenum alloy wire. The molybdenum rod heating element is made of pure molybdenum rods with a diameter of 5-16mm and a content of 99.95% high-temperature molybdenum. indivual. The length of the heating part is 300-1200mm. The length of the U-shaped heating element is between 1000-4000mm. The operating temperature is 1000-1800 ℃, and it can be used in various atmosphere furnaces or vacuum furnaces. The corrosion resistance is about twice that of silicon carbon rods and silicon molybdenum rods.


    2. Specification Of Molybdenum Heat Element For Hot Zones:


    Special supplier of Mo heater element
    Fine shape according to customer's drawing

    Molybdenum Heat Element


    We provide heating elements for hot zones in the form of strip heaters, wire and rod elements, stranded-wire elements, or mesh heaters depending on the furnace design and operating temperature.


    1) Molybdenum Strip Heater


    Made of Mo, MoLa, TZM

    Very fine shape

    High mechanical and thermal stability

    Low creep deformation

    Supply heating elements according to user's drawing


    2) Molybdenum heater wire and rod


    Size: dia.0.3 - 3 mm x coil

    dia. 3 - 11 mm x 6000 mm long

    Very fine surface and density uniformity



    3. Physical And Chemical Properties Of Molybdenum Heat Element For Hot Zones:


    Product name:Mo heater element
    Tensile strength610 Mpa
    Elongation≥10%
    Purity≥99.95%,99.97%
    Size:

    dia.0.3 - 3 mm x coil

    dia. 3 - 11 mm x 6000 mm long

    Surface:black
    Use temperature1100~1800°C
    Quantitative analysis
    ElementCaPbFeMgSiBiAlNiPCu
    Concentration(%)0.00060.00060.0010.00060.0030.00060.0030.00060.0010.0006
    ElementCOSb
    Concentration(%)0.0010.0050.0006
    Purity(Metallic Base) Mo99.95%
    ElementNiMgFeSnAlSbSiPCd
    Concentration(%)0.0014<0.00010.0047<0.00010.0002<0.0001<0.001<0.001<0.001
    ElementCNBiPbCu
    Concentration(%)0.00210.03<0.0001<0.0001<0.0005
    Purity(Metallic Base) Mo≥99.97

    4. Application Of Molybdenum Heat Element For Hot Zones:

    Molybdenum Heater element can be used for Hydrog enenvironment furnace, vacuum furnace etc.


    Other Parts For Hot Zones:



    Mo crucible Mo hammer Mo sheet Mo fastener
