    Flat Bottom Stamped Pure Tungsten Boat For Evaporation #210 #310 #215 #315 #320 Tungsten Evaporation Boat

    Ask Lasest Price
    Brand Name : PRM
    Model Number : custom
    Certification : ISO9001
    Price : $5~50/pc
    Payment Terms : T/T
    Supply Ability : 20000pcs/month
    Delivery Time : 10~15work days
    MOQ : 1pc
    • Product Details
    • Company Profile

    Flat Bottom Stamped Pure Tungsten Boat For Evaporation #210 #310 #215 #315 #320 Tungsten Evaporation Boat

    Flat Bottom Stamped Tungsten Boat


    1. Description of Flat Bottom Stamped Tungsten Boat:


    Flat bottom tungsten boat is a kind of stamped tungsten boat. It is formed by high pressure stamping of tungsten sheet. It is very temperature resistant and has excellent electrical conductivity. It is widely used in vacuum coating industry and sintering furnace sintering or vacuum annealing ship industry.


    2. Size of Flat Bottom Stamped Tungsten Boat:


    TyepPictureSizeSurface

    210,310

    Flat Bottom

    Tungsten Boat

    Flat Bottom Stamped Pure Tungsten Boat For Evaporation #210 #310 #215 #315 #320 Tungsten Evaporation Boat

    0.2/0.3*10*100:

    Length of groove=50mm,

    Depth of groove=2.5-2.6mm,Bottom length=40mm,

    Width of bottom=4mm

    Bright

    210,310

    Flat Bottom

    Tungsten Boat

    Flat Bottom Stamped Pure Tungsten Boat For Evaporation #210 #310 #215 #315 #320 Tungsten Evaporation Boat

    0.2/0.3*10*100:

    Length of groove=40mm,

    Depth of groove=2.5-2.6mm,

    Bottom length=30mm,

    Width of bottom=4mm

    Bright

    215,315

    Flat Bottom

    Tungsten Boat

    Flat Bottom Stamped Pure Tungsten Boat For Evaporation #210 #310 #215 #315 #320 Tungsten Evaporation Boat

    0.2/0.3*15*100:

    Length of groove=40mm,

    Depth of groove=2.4-2.5mm,

    Bottom length=30mm,

    Width of bottom=8mm

    Bright

    215,315

    Flat Bottom

    Tungsten Boat

    Flat Bottom Stamped Pure Tungsten Boat For Evaporation #210 #310 #215 #315 #320 Tungsten Evaporation Boat

    0.2/0.3*15*100:

    Length of groove=50mm,

    Depth of groove=2.8mm,

    Bottom length=40mm,

    Width of bottom=8mm

    Bright

    220,320

    Flat Bottom

    Tungsten Boat

    Flat Bottom Stamped Pure Tungsten Boat For Evaporation #210 #310 #215 #315 #320 Tungsten Evaporation Boat

    0.2/0.3*20*100:

    Length of groove=40mm,

    Depth of groove=2.6-2.7mm

    Bottom length=30mm,

    Width of bottom=15mm

    Bright

    220,320

    Flat Bottom

    Tungsten Boat

    Flat Bottom Stamped Pure Tungsten Boat For Evaporation #210 #310 #215 #315 #320 Tungsten Evaporation Boat

    0.2/0.3*20*100:

    Length of groove=50mm,

    Depth of groove=4.0mm,

    Bottom length=40mm,

    Width of bottom=13mm

    Bright

    Also we can process custom as per customer's drawing.



    3. Advantage of Flat Bottom Stamped Tungsten Boat:


    The yield of stamped tungsten boat is high. Because this type of tungsten boat is prepared by stamping equipment and stamping dies, the size and shape of the stamped tungsten boat are more precise. The mold has a long service life and is not easy to be damaged. Therefore, the stamped tungsten boats produced in the same batch are almost identical in shape and stable in quality. The stamping equipment has a certain pressure accuracy, so it will not damage the surface quality of the finished tungsten boat.

    4. Shortcoming of Flat Bottom Stamped Tungsten Boat:


    Noise and vibration are generated during the stamping process. At the same time, because the mold is an essential material for the stamping process, the quality of the mold determines the quality of the tungsten boat.
