    Pure 99.95% Molybdenum Boat Sheets For Evaporation Coating Evaporation Boat Moly Boat Folding Boats Evaporation Coating

    Ask Lasest Price
    Brand Name : PRM
    Model Number : custom
    Certification : ISO9001
    Price : $5~20/pc
    Payment Terms : T/T
    Supply Ability : 20000pcs/month
    Delivery Time : 7~10 work days
    MOQ : 1pc
    • Product Details
    • Company Profile

    Pure 99.95% Molybdenum Boat Sheets For Evaporation Coating Evaporation Boat Moly Boat Folding Boats Evaporation Coating

    Pure 99.95% Molybdenum Boat For Evaporation Coating


    1. Description of Pure 99.95% Molybdenum Boat For Evaporation Coating:


    Molybdenum boat is one of molybdenum products, it is also often called evaporated molybdenum boat or coated molybdenum boat, which is a kind of high temperature resistant vessel. Molybdenum boats are made of molybdenum sheets by high temperature stamping. They are divided into different types according to different processing methods, including stamping boats, folding boats, welding boats and riveting boats. It has good electrical conductivity, thermal conductivity, high temperature resistance, corrosion resistance and wear resistance, so it is mainly used in coating technology, electronic industry, power engineering and other fields, such as capacitor sintering, vacuum thermal evaporation, nuclear fuel sintering, thermocouple housing etc.


    2. Type of Pure 99.95% Molybdenum Boat For Evaporation Coating:


    Type
    Thickness( mm)
    Width( mm)
    Length( mm)
    Manufacturer
    #207
    0.2
    7
    100
    Shaanxi Peakrise Metal CO.,Ltd
    #215
    0.2
    15
    100
    #308
    0.3
    8
    100
    #310
    0.3
    10
    100
    #315
    0.3
    15
    100
    #413
    0.4
    13
    50
    #525
    0.5
    25
    78


    3. Main Specifications and Classification of Pure 99.95% Molybdenum Boat For Evaporation Coating:


    Molybdenum boat with a flat grove is ideal for materials with great wetability.


    Molybdenum boat with a V-groove is appropriate for materials with low wetability.


    Molybdenum boat with an oval groove that is appropriate for molten materials.


    Molybdenum boat with a spherical groove is ideal for transporting precious metals like gold and silver.


    This design, known as the Narrow Slot Molybdenum Boat, keeps vapor deposition material from adhering to the filament clip.


    Aluminum evaporation boat: To help the boat withstand the molten material with strong corrosion resistance, the surface of the body has been covered with aluminum oxide.


    4. Chemical content of Pure 99.95% Molybdenum Boat For Evaporation Coating:


    Quantitative analysis
    Chemical ElementCuPbFeMgSiCaAlBiPNi
    Concentration(%)0.00060.00060.0010.00060.0030.00060.0030.00060.0010.0006
    Chemical ElementCOSb
    Concentration(%)0.0010.0050.0006
    Purity(Metallic Base) Mo≥99.95%

    5. Advantage of Pure 99.95% Molybdenum Boat For Evaporation Coating:


    Molybdenum has high strength, high melting point, corrosion resistance, wear resistance.
