    Forged Pure Tungsten Round Bar Rod W1 Purity 99.95% Diameter 8mm Tungsten Rod Polished Tungsten Bar Vacuum Furnace Part

    Forged Pure Tungsten Rod W1 Purity 99.95% Diameter 8mm Rod

    1. Forged 8mm diameter pure tungsten rod description:

    With the aid of a specialized high-temperature powder metallurgy technique, metal powder is refined at a particular high temperature to create tungsten rods. Due to its low thermal expansion coefficient, high thermal conductivity, and strong electrical resistance, tungsten rod finds widespread application across a variety of industries. For instance, filaments, high-speed tools, automobile automatic products, lead-in lines, support lines, printer needles, different electrodes, quartz furnaces, and sputtering targets.

    2. Forged W1 Diameter 8mm Pure Tungsten Rod Physical and Chemical Properties:

    1). Forging tungsten rod

    1.1 Purity: W≥99.95%;

    1.2 Density:≥19.3g/cm3;

    1.3 Linearity:≤1%;


    2). Sintering tungsten rod

    2.1 Purity:W≥99.95%;

    2.2 Density:≥18.3g/cm3;

    2.3 Linearity:≤3%



    3. Measurements and Tolerances of Forged Pure Tungsten Rod W1 Diameter 8mm rod:


    Unit:mm

    Delivery conditionDiameterDiameter tolerance(%)Max length
    Forging or Sintering<20±0.12000
    20~30±0.11200
    30~60±0.11000
    60~70±0.2800
    70~90±0.2600
    >90Manufacture according to customers’ requirements
    4. Manufacture process and Equipment of Forged Pure Tungsten Rod W1 Diameter 8mm rod:
    Sintering tungsten rod
    ItemProcessEquipmentQuality check point
    1Tungsten powder
    2SievingHigh frequency vibrating sieve1 Purity of tungsten powder
    3Mixed powderV shape mixer2 Mixed tungsten powder
    4Check
    5Isostatic pressingIsostatic pressing machine1 Measurements, unit net weight
    6Check2 Surface quality
    7IF sinteringIF induction sintering furnace1 Measurement, unit net weight, density
    8Alignment200T pressing machine2 Linearity ,Surface quality
    9Check3 Quality standard:GB/T4187-1984
    10Package4 Show certificate of quality

    Forging tungsten rod
    ItemProcessEquipmentQuality check point
    1Sintering tungsten rod1 Measurements
    2ForgeForging air-hammer2 Density
    3MachiningLathe, grinder3 Linearity ,Surface quality
    4Check4 Quality standard:GB/T4187-1984
    5Package5 Show certificate of quality


    5. Uses for W1 Diameter 8mm Forged Pure Tungsten Rod:

    Pulling tungsten wire and forging tungsten rod are the two main uses for sintering tungsten rod as a material. Due to tungsten's dyslectic point, electrodes, heating elements, connectors, and support rods in high-temperature furnaces as well as tungsten crucible supports are frequently made of high-purity, high-density, and superior high-temperature proof of creep deformation.
