    MoCu30 Molybdenum Copper Alloy Sheet 2mm Thickness For Electronic Heat Sink

    Ask Lasest Price
    Brand Name : PRM
    Certification : ISO9001
    Price : Negotiate
    Delivery Time : 7~10days
    Payment Terms : T/T,L/C
    Supply Ability : 50000pcs/month
    Model Number : custom
    • Product Details
    • Company Profile

    MoCu30 Molybdenum Copper Alloy Sheet 2mm Thickness For Electronic Heat Sink

    Product Description:

    Molybdenum copper alloy sheet is an alloy material composed of molybdenum and copper. Molybdenum-copper alloy has the characteristics of high melting point, good thermal conductivity, excellent corrosion resistance and high strength, so it is widely used in many industrial fields.


    Grade

    Mo content

    Wt%

    Density

    g/cm3

    Thermal expansion coefficient ×10-6

    CTE(20℃)

    Thermal Conductivity

    W/(M·K)

    ConductivityμΩm

    Hardness

    HV

    85MoCu85±2%9.986.8160~1800.05210
    80MoCu80±2%9.917.7170~1900.046190
    70MoCu70±2%9.779.1200~2500.04180
    65MoCu65±2%9.709.7210~2700.038176
    60MoCu60±2%9.6410.3220~2800.034170

    Applications:

    Molybdenum-copper alloy sheet is often used in the manufacture of heat dissipation elements in high-temperature equipment and electronic devices. Due to the high melting point and good thermal conductivity of molybdenum-copper alloy, it can effectively conduct heat from the heat source to the surrounding environment and play a role in heat dissipation. Therefore, in some applications that require high temperature resistance, such as aerospace, power electronics and semiconductors, molybdenum-copper alloy sheets are often used as heat sinks, heat dissipation bases or other heat dissipation components.


    In addition, the molybdenum-copper alloy sheet also has good electronic packaging performance, and can provide good electromagnetic shielding and electrothermal performance.


    Therefore, it is also widely used in the packaging and connection fields of electronic devices, such as high-frequency electronic packaging, semiconductor packaging and microelectronic packaging.


    Support and Services:

    Molybdenum Copper Alloy is a high-performance alloy with excellent electrical and thermal conductivity properties. It is ideal for applications requiring high electrical and thermal conductivity, and it is widely used in the electronics industry. Our technical support and services for Molybdenum Copper Alloy include:


    • Design advice for optimal performance and cost-effectiveness
    • On-site consultation and installation
    • Troubleshooting and repair services
    • Upgrades, maintenance, and refurbishment services
    • Product testing and certification
    • Technical support over the phone, email, and live chat

    Packing and Shipping:

    Packaging and Shipping:


    Molybdenum copper alloy is packaged and shipped in accordance with industry standards and customer requirements. All items are carefully wrapped and protected with shock-resistant materials to prevent any damage during transit.


    Packages are labeled with content descriptions and shipped via reliable, cost-effective transport services. We also offer customized packaging solutions to meet individual needs, such as vacuum packing, nitrogen filling, and special protective cases.
