    M6 M8 M10 Molybdenum Bolt Threaded Rod Length 1000mm Vacuum Furnace Parts

    Ask Lasest Price
    Brand Name : PRM
    Model Number : custom
    Certification : ISO9001
    Price : $0.1~5.0/pc
    Payment Terms : T/T
    Supply Ability : 50000pcs/month
    Delivery Time : 7~10 work days
    • Product Details
    • Company Profile

    M6 M8 M10 Molybdenum Bolt Threaded Rod Length 1000mm Vacuum Furnace Parts

    Molybdenum Bolt Length 1000mm Molybdenum Threaded Rod Vacuum Furnace Parts


    1. Information Of Molybdenum Bolt Mo Threaded Rod:


    Molybdenum screw is a high-performance alloy material, its main component is molybdenum, and it also contains a small amount of other metal elements, such as niobium and titanium. Molybdenum screw has excellent high temperature resistance, corrosion resistance, excellent mechanical properties and dimensional stability. It is widely used in many application fields, such as aviation, aerospace, nuclear industry and so on.


    2. Size Of Molybdenum Bolt Mo Threaded Rod:


    Size:M2~M20

    Grade: Mo1,TZM,Mo-La

    Purity: 99.95%,99.97%

    Surface: polised,black

    We also process according to customer’s drawings


    Item No.DIN-StabdardDesciption in EnglishISO-StandardGB-Standard
    1DIN 1Taper pinsISO2339GB117
    2DIN7Parallel pinsISO2339GB119-86
    3DIN84Slotted cheese head screwISO1207GB65-85
    4DIN125-APlain washersISO7089GB97.1-85
    5DIN125-BMedium washersISO7090GB97.2-85
    6DIN126Plain washersISO7091
    7DIN558Hexagon screwsISO4018
    8DIN601Hexagon blotsISO4016
    9DIN923Slotted pan head screw with shoulderGB830-88
    10DIN931Hexagon head screwsISO4014GB5782-86
    11DIN933Hexagon head screwsISO4017GB5783-86
    12DIN934Hexagon full nutsISO4032GB6170-86
    13DIN935Hexagon slotted and castle nutsISO7035GB6178-86
    14DIN7972Countersunk flat head tapping screws with slotISO1482GB5283-85
    Etc.

    3. Chemical Of Molybdenum Bolt Mo Threaded Rod:


    Quantitative analysis
    ElementNiMgFePbAlBiSiCaPCu
    Concentration(%)0.00060.00060.0010.00060.0030.00060.0030.00060.0010.0006
    ElementCOSb
    Concentration(%)0.0010.0050.0006
    Purity(Metallic Base) Mo99.95%
    ElementNiMgFePbAlBiSiCdP
    Concentration(%)0.0014<0.00010.0047<0.00010.0002<0.0001<0.001<0.001<0.001
    ElementCNSbSnCu
    Concentration(%)0.00210.03<0.0001<0.0001<0.0005
    Purity(Metallic Base) Mo≥99.97


    4.Technical Parameters Of Molybdenum Bolt Mo Threaded Rod:

    Density: 10.2g/cm³
    Tensile strength: ≥620MPa
    Bending strength: ≥440MPa
    Elongation: ≥10%
    Hardness: ≥220HB
    Coefficient of thermal expansion: 5.4×10-6/°C (20°C~1000°C)


    M6 M8 M10 Molybdenum Bolt Threaded Rod Length 1000mm Vacuum Furnace PartsM6 M8 M10 Molybdenum Bolt Threaded Rod Length 1000mm Vacuum Furnace Parts


    5. Advantages Of Molybdenum Bolt Mo Threaded Rod:


    Good high temperature resistance: the melting point of molybdenum screw is as high as 2610°C, it can be used in high temperature environment for a long time, and maintain good mechanical properties and dimensional stability.


    Good corrosion resistance: molybdenum screw can be used in most chemical media, including strong acid, strong alkali, salt solution, etc.
    Excellent mechanical properties: molybdenum screw has high hardness, high strength and good toughness.


    Good processing performance: molybdenum screw can be used for drilling, turning, milling and other common processing methods, and the processed surface has a high finish.


    Good stability: Molybdenum screw has a low coefficient of thermal expansion and can maintain dimensional stability even in high temperature environments.
