    Gr2 Gr1 Gr5 Hot / Cold Rolling Titanium Plate 0.5 - 100mm Thickness

    Ask Lasest Price
    Brand Name : PRM
    Model Number : Custom
    Certification : ISO9001
    Price : Negotiate
    Payment Terms : T/T
    Supply Ability : 5000kgs/month
    Delivery Time : 3~5days
    • Product Details
    • Company Profile

    Gr2 Gr1 Gr5 Hot / Cold Rolling Titanium Plate 0.5 - 100mm Thickness

    China Titanium Gr1 Gr2 Gr5 Titanium Plate


    1. Information Of Titanium Plate:


    Name: Titanium Plate

    Grade: Gr1 Gr2 Gr5 Gr7 Gr9 Gr11 Gr23,TA1 TA2 TA0,BT1-1 BT1-0

    Thickness: 0.5~100mm

    Width: ≤ 2500mm

    Length: ≤ 12meters


    Usually Standard size: 1000*2000mm, 1200*2000mm Or can process according to customer's request.


    Standard: ASTM B265, ASME SB265,ASTM F136/67, AMS 4911,AMS 4905, AMS 4907, MIL-T-9046

    Processing Method: hot rolling, cold rolling

    Surface: bright, sandblasting



    2. Chemical Content of Gr2 Gr5 Gr9 Titanium Plate:


    NCHFeOAlVPaMoNiTi
    Gr 10.030.080.0150.200.18/////bal
    Gr 20.030.080.0150.300.25/////bal
    Gr 50.050.080.0150.400.205.5~6.753.5~4.5///bal
    Gr 70.030.080.0150.300.25//0.12~0.25//bal
    Gr 90.030.080.0150.250.152.5~3.52.0~3.0///bal
    Gr120.030.080.0150.300.25///0.2~0.40.6~0.9bal

    3. Mechanical Properties of Gr2 Gr5 Gr9 Titanium Plate:


    GradeMechanical Properties (>%)

    Tensile Strengh

    (min)

    Yield Strengh

    (0.2% offset)

    Elongation

    (min %)

    KsiMpaMinMax
    KsiMpaKsiMpa
    Gr1352402017045310240
    Gr250345402756545020
    Gr365450553808055018
    Gr480550704839565015
    Gr5130895120828--10c
    Gr750345402756545020
    Gr99062070483--15D
    Gr127048350345--180

    4. Common use of titanium sheet/plate:


    Aerospace industry: Titanium plates are widely used in the aerospace field. It can be used to manufacture aircraft structures, engine components, gas turbine blades, spacecraft casings, and more. The high strength, light weight and corrosion resistance of titanium plates help improve aircraft performance and fuel efficiency.


    Chemical industry: Due to its excellent corrosion resistance, titanium plate is widely used in the chemical industry. Titanium plates can be used to manufacture chemical containers, reactors, heat exchangers, storage tanks, etc. to resist the erosion of corrosive media.


    Marine Industry: Titanium plates are widely used in marine environments due to their extremely high resistance to corrosion from seawater and salt water. It can be used to manufacture offshore platforms, marine pipelines, ship components, seawater treatment equipment, etc.


    Medical devices: Titanium plates have good compatibility with human tissue and will not cause allergic reactions, so they are widely used in the manufacture of medical devices. It can be used to make artificial joints, bone plates, dental implants and more.


    Oil and gas industry: Titanium plates are used in the oil and gas industry to manufacture subsea oil well equipment, oil and gas storage tanks, pipelines, etc. Its corrosion resistance enables titanium plates to withstand harsh working environments and corrosive media.


    Automotive Industry: Titanium sheets are used in the automotive industry to make engine covers, exhaust system components, chassis cover panels, etc. Its lightweight and high-strength properties help reduce vehicle weight and improve fuel efficiency and performance.


    In addition to the above application fields, titanium plate is also widely used in shipbuilding, food processing, electronic equipment, etc. Its excellent performance and versatility make it an important material in many industries.
