    ASME B16.9 Titanium Tee Equal Diameter Tee TA1 TA2 TA10 TC4 Gr1 Gr2 Gr5

    Ask Lasest Price
    Brand Name : PRM
    Model Number : Custom
    Certification : ISO9001
    Price : Negotiate
    Payment Terms : T/T
    Supply Ability : 10ton/month
    Delivery Time : 5~7days
    • Product Details
    • Company Profile

    ASME B16.9 Titanium Tee Equal Diameter Tee TA1 TA2 TA10 TC4 Gr1 Gr2 Gr5

    Titanium Tee


    1. Information Of Titanium Tee/Equal Diameter Tee.


    Titanium tee is also called titanium pipe fitting tee or titanium tee fitting, titanium tee joint, etc. It is mainly used to change the direction of fluid and is used at branch pipes of main pipelines. Can be classified according to pipe diameter.


    Titanium tee type:


    Same diameter titanium tee
    Reducing diameter titanium tee
    Titanium positive tee
    Titanium inclined tee
    Titanium Threaded Tee
    Titanium ferrule tee
    Titanium socket tee


    Standard:ASME B16.9,SH3408,SH3409-96,SH3410-96,HG/T21635,DL/T 695,SY/T 0510,DIN 2615



    2. Size Of Titanium Tee/Equal Diameter Tee.


    Nominal diameterOutside diameterCenter to End
    D1D2
    DNNPSSeries ASeries BSeries ASeries BCM
    15×15×151/2×1/2×1/221.31821.3182525
    15×15×101/2×1/2×3/821.31817.3142525
    15×15×81/2×1/2×1/421.31813.7102525
    20×20×203/4×3/4×3/426.92526.9252929
    20×20×153/4×3/4×1/226.92521.3182929
    20×20×103/4×3/4×3/826.92517.3142929
    25×25×251×1×133.73233.7323838
    25×25×201×1×3/433.73226.9253838
    25×25×151×1×1/233.73221.3183838
    32×32×321.1/4×1.1/4×1.1/442.43842.4384848
    32×32×251.1/4×1.1/4×142.43833.7324848
    32×32×201.1/4×1.1/4×3/442.43826.9254848
    32×32×151.1/4×1.1/4×1/242.43821.3184848

    Other sizes or drawing,pls contact with us online or email.


    3. Application Of Titanium Tee/Equal Diameter Tee.


    Titanium tees are widely used in chemical, food, medicine, aerospace, shipbuilding, sewage treatment and other industries due to their corrosion resistance, high temperature resistance, non-magnetic conductivity, non-toxic and harmless, and strong stability.


    Titanium tee related products



    Ti elbow Ti Flange Ti tube




    Please click below button for learn more our products.
