0.3mm TZM Molybdenum Alloy Wire Electrolytic Polishing Black For Furnace Components

    Buy cheap 0.3mm TZM Molybdenum Alloy Wire Electrolytic Polishing Black For Furnace Components from wholesalers

    Buy cheap 0.3mm TZM Molybdenum Alloy Wire Electrolytic Polishing Black For Furnace Components from wholesalers
    • Buy cheap 0.3mm TZM Molybdenum Alloy Wire Electrolytic Polishing Black For Furnace Components from wholesalers
    • Buy cheap 0.3mm TZM Molybdenum Alloy Wire Electrolytic Polishing Black For Furnace Components from wholesalers
    • Buy cheap 0.3mm TZM Molybdenum Alloy Wire Electrolytic Polishing Black For Furnace Components from wholesalers
    • Buy cheap 0.3mm TZM Molybdenum Alloy Wire Electrolytic Polishing Black For Furnace Components from wholesalers

    0.3mm TZM Molybdenum Alloy Wire Electrolytic Polishing Black For Furnace Components

    Ask Lasest Price
    Brand Name : PRM
    Model Number : custom
    Certification : ISO9001
    Price : Negotiate
    Payment Terms : T/T
    Supply Ability : 2000kgs/month
    Delivery Time : 7~10 work days
    • Product Details
    • Company Profile

    0.3mm TZM Molybdenum Alloy Wire Electrolytic Polishing Black For Furnace Components

    Product Description:

    TZM molybdenum alloy wire is composed of molybdenum, zirconium and titanium. The typical composition ratio is about 85-99% molybdenum, about 0.5% titanium, about 0.08% zirconium.


    Comparison of physical properties between TZM alloy wire (molybdenum-zirconium-titanium alloy) and pure molybdenum:


    Material
    Desnity /g·cm-3
    Melting Point /℃
    Boiling point/℃
    TZM alloy
    (Ti0.5/Zr0.08)
    10.22
    2617
    4612
    Pure Mo
    10.29
    2610
    5560

    Mechanical Properties of TZM Alloy Wire:
    Mechannical
    Properties
    Elongation
    /%
    Elastic
    Modulus
    /GPa
    Yield
    Strength
    /MPa
    Tensile
    strength
    /MPa
    Fracture
    toughness
    /(MP·m1/2)
    Data
    <20
    320
    560~1150
    685
    5.8~29.6

    Diameter: 0.013~3.0mm

    Surface: Electrolytic polished,black,white surface

    Use Temperature:1600~1800℃



    Applications:

    PRM TZM Molybdenum Alloy Wire: Applications and Uses

    High-temperature application: Due to its excellent high-temperature resistance, TZM molybdenum alloy wire is often used as electrodes and wires in melting and melting processes such as electric melting, arc melting, and electron beam melting in high-temperature environments.


    Electronic industry: Due to its good electrical conductivity and corrosion resistance, the alloy wire can be used in electronic devices, semiconductor manufacturing, vacuum tubes, electron beam welding and other fields.


    Chemical industry: The corrosion resistance of TZM molybdenum alloy wire makes it suitable for applications in corrosive environments such as chemical reactors, electrolytic cells, and electrolytic cells.


    Other applications: the alloy wire can also be used in aerospace, aero-engine, nuclear industry, medical equipment and other fields.

    Packing and Shipping:

    FAQ:

    Q1: What is PRM TZM Molybdenum Alloy Wire?

    A1: PRM TZM Molybdenum Alloy wire is a molybdenum alloy containing titanium, zirconium and carbon. It is produced by PRM, a company located in China.


    Q2: What is the composition of PRM TZM Molybdenum Alloy Wire?

    A2: PRM TZM Molybdenum Alloy wire mainly contains molybdenum, with small amounts of titanium, zirconium and carbon.


    Q3: What are the benefits of PRM TZM Molybdenum Alloy Wire?

    A3: PRM TZM Molybdenum Alloy wire has excellent mechanical strength, creep resistance and corrosion resistance, making it suitable for high-temperature applications. It also has high thermal conductivity and electrical conductivity.


    Q4: What are the applications of PRM TZM Molybdenum Alloy Wire?

    A4: PRM TZM Molybdenum Alloy wire is usually used for high-temperature applications such as furnace parts, heating elements and thermocouples. It is also used for springs, electrodes and high-temperature components.


    Q5: What is the production process of PRM TZM Molybdenum Alloy Wire?

    A5: PRM TZM Molybdenum Alloy wire is produced by melting the raw materials in a vacuum induction furnace and then pouring the molten alloy into molds. The alloy is then cooled and forged to the desired shape.
