    High Purity 99.95% 99.99% Tantalum Wire / Tantalum Alloy Wire 0.1 - 4mm Diameter

    Ask Lasest Price
    Brand Name : PRM
    Model Number : Wire
    Certification : ISO9001
    Price : Negotiate
    Payment Terms : T/T, L/C
    Supply Ability : 2000kgs/month
    Delivery Time : 7~10 work days
    • Product Details
    • Company Profile

    High Purity 99.95% 99.99% Tantalum Wire / Tantalum Alloy Wire 0.1 - 4mm Diameter

    High Purity 99.95% 99.99% Tantalum Wire


    1. Specification Of Tantalum Wire & Tantalum Alloy Wire:


    Tantalum wire, Tantalum alloy wire
    Grade: RO5200, RO5252, RO5255,RO5240
    Size: Dia0.3~4mm
    Standard:ASTM B 365-98
    Purity: >99.95%,99.99%

    Surface: Bright

    Condition: annealed


    Wire, Diameter, inch (mm)
    GradeDiameter,inch (mm)tensile strength,psi (MPa),≥Elongation, %, ≥
    RO5200/RO54000.010(0.254)~0.0149(0.379)35000 (241)10
    0.015(0.381)~0.0249(0.633)35000 (241)15
    0.025(0.635)~0.124(3.14)30000 (207)20
    RO52520.010(0.254)~0.0149(0.379)40000 (276)5
    0.015(0.381)~0.0249(0.633)40000 (276)10
    0.025(0.635)~0.124(3.14)40000 (276)15
    RO52550.010(0.254)~0.0149(0.379)70000 (482)5
    0.015(0.381)~0.0249(0.633)70000 (482)10
    0.025(0.635)~0.124(3.14)70000 (482)15
    RO52400.010(0.254)~0.0149(0.379)40000 (276)10
    0.015(0.381)~0.0249(0.633)40000 (276)15
    0.025(0.635)~0.124(3.14)40000 (276)20

    GradeMain elements Impurity content less than %
     TaNbFeSiNiWMoTiNbOCHN
    Ta1Remain——0.0050.0050.0020.010.010.0020.040.020.010.00150.01
    Ta2Remain——0.030.020.0050.040.030.0050.10.030.010.00150.01
    TaNb3Remain<3.50.030.030.0050.040.030.005——0.030.010.00150.01
    TaNb20Remain17.0~23.00.030.030.0050.040.030.005——0.030.010.00150.01
    Ta2.5WRemain 0.0050.0050.00230.010.0020.040.020.010.00150.01
    Ta10WRemain 0.0050.0050.002110.010.0020.040.020.010.00150.01


    2. Application Of Tantalum Wire & Tantalum Alloy Wire:


    Capacitor grade tantalum wire is mainly used to make the anode lead of tantalum electrolytic capacitors. The capacitor-grade tantalum wire currently produced by our company can be divided into more than 30 varieties according to different conditions and specifications.


    The smallest diameter tantalum wire is Φ0.10mm. It can also be made into tantalum yarn or tantalum mesh. Tantalum wire is the key material for making tantalum capacitors. Tantalum capacitors are the best capacitors.

    About 65% of the world's tantalum is used in this field. Used to compensate for muscle tissue, and can be used to suture nerves and tendons. Our company can provide tantalum wire in different states and specifications.


    The smallest diameter tantalum wire is Φ0.1mm. Tantalum wire can also be used to make heating components of vacuum high-temperature furnaces.


    3. Package & Shipping:
